美標鍛造式長桿波紋管截止閥Forging style long stem bellow sealed globe valve ace.to ANSI
DZBCJH型(中部焊接式)
CL150-300-600
螺栓連接閥蓋，縮徑，明桿支架(OS&Y)
Bolted bonnet, reducing port outside screw and yoke(OS & Y)
末端連接為連接法蘭或對焊連接，設計按BS5352\MSS-SP-117
Flange-welded or butt-welded ends;design to BS5352\MSS-SP-117
規格Specification (NPS)
R.P
1/4
3/8
1/2
3/4
1
1¼
1½
2
結構長度(mm) Face to face
CL 150
L(RF) L1(BW)
─
─
108
117
127
140
165
203
CL300
─
─
152
178
203
216
229
267
CL600
─
─
165
190
216
229
241
292
手輪直徑(mm)Handwheel diameter
W
─
─
100
100
125
160
160
180
中心高度(mm)Height
CL150/CL300
H
─
─
340/350
340/350
360/375
380/400
450/470
540/570
CL600
─
─
360
360
390
430
500
600
流道孔徑(mm)Flow port dimension
d
─
─
9
13
17.5
23
30
35
重量Weigh (Kg)
CL150
RF/BW
─
─
3.67/3
43/3.6
6.3/57
10.5/9.5
11.5/9.8
19.5/16
CL300
RF/BW
─
─
4/3.2
4.8/4
7.3/67
13/11
14.5/12
22/18
CL600
RF/BW
─
─
5.8/47
8.1/6
12.5/9
18/14
24.5/18
42/36
DZBCJF型(中部法蘭式)
CL150-300-600
螺栓連接閥蓋，縮徑，明桿支架(OS&Y)
Bolted bonnet, reducing port outside screw and yoke(OS & Y)
末端連接為連接法蘭或對焊連接，設計按BS5352\MSS-SP-117
Flange-welded or butt-welded ends;design to BS5352\MSS-SP-117
